Quick Details

  • Place of Origin: Guangdong, China (Mainland)
  • Brand Name: JCN
  • Model Number: 5watt
  • Material: Polycrystalline Silicon
  • Size: 205*180*150mm
  • Number of Cells: 1pcs
  • Max. Power: 23watt
  • solar panel: 5W
  • appliance: home lighting,outside lighting
  • battery: 4AH
  • Storage battery: lead acid battery
  • controller: 2A
  • size: 205*180*150mm
  • OEM: YES
  • ODM: YES
  • weight: 3.5kg
  • led lights: 2W

Packaging & Delivery

Packaging Details 1set per box,4 sets/carton
Delivery Time 10-20 workdays after the order confirmed

                              smal system with led lighting solar lighting kits

Product features:

It is DC power supply system, designed especially for users in remote locations with few access to electricity.



Functions:



A. The key function of overcharge & over discharged protection can extend the life span of the battery. The processor protects against arcing during the low voltage conditions.







B.  The standby function: Following five minutes after startup, if no output loads are detected the system will automatically enter into a low power consumption standby mode.







C.USB output overload protection: The USB output will shut down automatically if the maximum output current exceeds 1000mA when charging for mobiles, MP3, and digital camera etc.







D. Overload protection: The output will shut down automatically when current exceeds 3 Amps







E. Independent Charging & DischargingThe system can charge and discharge independently.







F. Load indicator: A battery indicator light will display red when charging, and blue when the system is fully charged.









Parameters:
solar panel:5W poly crystalline
battery:12V/4AH lead acid battery

led lights:2W 2pcs with 5m cable(optional)

picture for your reference:
whole system

led lights:2W or 3W available according to your requirements




lighting time:
2pcs 2 watt led lights: more than10 hours
charge time:
full charged time by solar panel:about 18hours

solar system control panel


with battery capacity indicator and 4pcs 12V output,a USB output.

welcome to our booth and our factory!
